ESTEL DJM12100 12V 100Ah General Purpose Lead Acid Battery High Capacity Power Solution for Telecom UPS and Energy Storage Systems

ESTEL DJM12100 12V 100Ah General Purpose Lead Acid Battery High Capacity Power Solution for Telecom UPS and Energy Storage Systems
ESTEL DJM12100 12V 100Ah General Purpose Lead Acid Battery High Capacity Power Solution for Telecom UPS and Energy Storage Systems ESTEL DJM12100 12V 100Ah General Purpose Lead Acid Battery High Capacity Power Solution for Telecom UPS and Energy Storage Systems ESTEL DJM12100 12V 100Ah General Purpose Lead Acid Battery High Capacity Power Solution for Telecom UPS and Energy Storage Systems ESTEL DJM12100 12V 100Ah General Purpose Lead Acid Battery High Capacity Power Solution for Telecom UPS and Energy Storage Systems ESTEL DJM12100 12V 100Ah General Purpose Lead Acid Battery High Capacity Power Solution for Telecom UPS and Energy Storage Systems

Büyük resim :  ESTEL DJM12100 12V 100Ah General Purpose Lead Acid Battery High Capacity Power Solution for Telecom UPS and Energy Storage Systems

Ürün ayrıntıları:
Place of Origin: China
Marka adı: ESTEL
Sertifika: ISO9001, CE, 3C, FCC, TLC
Model Number: DJM12100
Ödeme & teslimat koşulları:
Minimum Order Quantity: 100000
Fiyat: 30-120
Packaging Details: carton packing
Payment Terms: T/T
Supply Ability: 100000
İletişim
Detaylı ürün tanımı
Rated Voltage: 12V Nominal Capacity: 100Ah
Dimensions (L×W×H): 330±2mm × 173±2mm × 212±2mm (13.0×6.81×8.35 inches) Total Height (incl. terminals): 220±2mm (8.66 inches)
Weight: 30.5kg (67.2 lbs) Terminal Type: M8
Container Material: ABS Extended Service Life: 12-year floating life at 25°C

ESTEL DJM12100 12V 100Ah General Purpose Lead Acid Battery High Capacity Power Solution for Telecom UPS and Energy Storage Systems





Overview



ESTEL DJM12100 is a robust 12V 100Ah general-purpose lead-acid battery designed for demanding applications requiring reliable long-term power. With its high-capacity design and superior discharge performance, this battery delivers consistent energy for critical systems. Featuring a durable ABS container and advanced safety technology, it offers up to 12 years of floating service life at 25°C. Certified to international standards, it is ideal for telecommunications, data centers, renewable energy storage, and industrial applications.





Specifications

  • Rated Voltage: 12V
  • Nominal Capacity (Cref@1.80V/cell): 100Ah
  • Dimensions (L×W×H): 330±2mm × 173±2mm × 212±2mm (13.0×6.81×8.35 inches)
  • Total Height (incl. terminals): 220±2mm (8.66 inches)
  • Weight: 30.5kg (67.2 lbs)
  • Terminal Type: M8
  • Container Material: ABS

Rated Capacity (25°C)

Discharge Rate Capacity Current
C20 105.0 Ah 5.25A
C10 100.0 Ah 10.0A
C5 84.5 Ah 16.9A
C3 77.1 Ah 25.7A
C1 58.1 Ah 58.1A





Performance



  • Max. Discharge Current: 1000A (5s)
  • Internal Resistance (25°C): ≈5.0mΩ
  • Operating Temperature:
    • Discharge: -20°C to 55°C (-4°F to 131°F)
    • Charge: -20°C to 40°C (-4°F to 104°F)
    • Storage: -15°C to 50°C (5°F to 122°F)
  • Recommended Temperature: 25±3°C (77±5°F)

Charging Parameters (25°C)

  • Max. Charging Current: 30A
  • Float Charge Voltage: 2.25–2.30V/cell
  • Equalization Charge Voltage: 2.35–2.40V/cell
  • Temperature Coefficient: -3mV/cell/°C (float), -4mV/cell/°C (equalization)

Self-Discharge

≤3% per month at 25°C

Discharge Characteristics (25°C)

Constant Current Discharge (A)

FinalVoltage 5min 10min 30min 1h 5h 10h 20h
1.85V/cell 197.7 140.5 78.8 50.9 15.8 9.55 5.07
1.80V/cell 224.8 159.5 85.8 52.7 16.6 10.0 5.25
1.60V/cell 279.7 196.8 92.0 58.1 17.8 10.5 5.49

Constant Power Discharge (W/cell)

Final Voltage 5min 10min 30min 1h 5h 10h 20h
1.85V/cell 369.1 264.4 150.7 98.5 31.1 19.0 10.1
1.80V/cel 412.9 295.8 162.7 101.4 32.6 19.9 10.4





Applications



  • Telecommunications
  • UPS & Data Centers
  • Energy Storage & Electric Systems
  • Emergency Lighting & Security
  • Medical & Electronic Equipment
  • Motive Power





Features



  • Extended Service Life: 12-year floating life at 25°C.
  • High Discharge Performance: Supports 1000A peak current (5s).
  • Safety Optimized: Special exhaust structure and leak-proof design.





Certifications



  • Standards: IEC 60896, GB/T19638, YD/T 799, DL/T 637
  • Certifications: UL, TLC, CE
  • Factory Certifications: IATF 16949, ISO 9001, ISO 14001, ISO 45001
